Ruijie Reyee RG-EW1200 Reyee 1200Mbps Dual-band Gigabit Wireless Router

RG-EW1200

Reyee 1200Mbps Dual-band Gigabit Wireless Router

Available
RRP RM188.00
Datasheet (PDF)

Specifications

Basic

Dimensions ( W×D×H )
182 mm x 120 mm x 32 mm (7.17 in. × 4.72 in. × 1.26 in. antennas not included)
Weight
0.22 kg (packages not included)
Wi-Fi Standards
Wi-Fi 5 (802.11ac)
MIMO
2.4 GHz, 2×2, MU-MIMO
5 GHz, 2×2, MU-MIMO
Max. Wi-Fi Speed
2.4 GHz: 300 Mbps
5 GHz: 867 Mbps
Channel Width
2.4 GHz: Auto/20/40 MHz
5 GHz: Auto/20/40/80 MHz
Antennas
4
Antennas Type
External Omnidirectional
Antenna Gain
2.4 GHz: 5 dBi
5 GHz: 5 dBi
WAN Port
1×10/100 Base-T Port
LAN Ports
3×10/100 Base-T Ports
Recommended Users
24
Max. Users
96
Power Supply
DC 12V/0.6A
Power Consumption
≤8.2W
Operation Frequency Bands
802.11b/g/n: 2.400 GHz to 2.483 GHz
802.11a/n/ac: 5.150 GHz to 5.350 GHz
802.11a/n/ac: 5.470 GHz to 5.725 GHz , 5.725 GHz to 5.850 GHz
country-specific restrictions apply
Transmit Power
Regular:
CE EIRP: ≤20 dBm (2.4 GHz)
≤27 dBm (5 GHz)
Operating Temperature
0 °C to +45 °C (32 °F to 113 °F)
Operating Humidity
5% to 95% Noncondensing
Certifications
CE, RoHS

Wireless

OFDMA
-
MU-MIMO
Yes
BSS Coloring
-
Maximum Number of SSIDs
6
SSID Hiding
Yes
Band Steering
Yes
Guest Wi-Fi
Yes
WPA/WPA2
Yes
WPA3
-
Roaming
Layer 2 Roaming
Blacklist
Yes
Reyee Mesh
Yes
Mesh Pairing by Hardware
Yes
Mesh Pairing by Mesh Button
Yes
Mesh Pairing by Eweb
Yes
Recommended Hop Count
≤5
Wi-Fi Optimization
Yes
QoS (WMM)
Yes
WPS
-
Transmission Power Adjustment
Yes

Hardware

CPU
MT7628
Flash
16M
RAM/SDRAM
64M
Color
White
System LED Indicator
Yes
Reyee Mesh LED Indicator
-
Reyee Mesh Button
Yes
Power Button
-
Reset Button
Yes
DC Connector Dimensions
5.5 mm x 2.1 mm x 10 mm
(0.22 in. × 0.08 in. × 0.39 in. antennas not included)

WAN

Static IP
Yes
DHCP
Yes
PPPoE
Yes
Learning PPPoE Account & Password
Yes
VLAN Tagging
Yes

LAN

DHCP Server
Yes
Client List
Yes
Static IP Assignment
Yes
Port-Based Flow Control
Yes

Features

IPv6
Yes
DDNS
Yes
IPTV
Yes
Alarm
Yes
Diagnosis
Yes
UPnP
Yes
ARP Binding
Yes
Port Mapping
Yes
DMZ Host
Yes
Rate Limitation of Terminals
Yes
Hardware Acceleration
Yes
MAC Address Cloning
Yes
Cloud Management
Yes
Repeater Mode
Yes
WISP Mode
-

Security

PPTP VPN Server
-
PPTP VPN Client
Yes
L2TP VPN Client
-
Parental Control
Yes
Protect TCP Flood Attacks
Yes
Protect ICMP Attacks
Yes
Protect UDP Flood Attacks
Yes

System

Default Access/Password
192.168.110.1
No Password Required by Default
URL Access
Yes
Local Upgrade
Yes
Online Upgrade
Yes
APP Upgrade
Yes
Syslog
-
Backup
Yes
Factory Reset
Yes
Language
Chinese
English
Vietnamese
Indonesian
Thai
Arabic
Traditional Chinese
Spanish
Russian
*Specifications are subject to change without prior notice.
