Ruijie Reyee RG-EW1200R Reyee 1200M Dual-band Mesh Wi-Fi Extender

RG-EW1200R

Reyee 1200M Dual-band Mesh Wi-Fi Extender

Available
RRP RM279.00
Datasheet (PDF)

Specifications

Basic

Dimensions ( W×D×H )
128 mm x 102 mm x 60 mm (5.04 in. × 4.02 in. × 2.36 in. antennas not included)
Weight
0.25 kg (packages not included)
Wi-Fi Standards
Wi-Fi 5 (802.11ac)
MIMO
2.4 GHz, 2×2, MU-MIMO
5 GHz, 2×2, MU-MIMO
Max. Wi-Fi Speed
2.4 GHz: 300 Mbps
5 GHz: 867 Mbps
Channel Width
2.4 GHz: Auto/20/40 MHz
5 GHz: Auto/20/40/80 MHz
Antennas
2
Antennas Type
External Omnidirectional
Antenna Gain
2.4 GHz: 4 dBi
5 GHz: 4 dBi
Port
1×10/100 Base-T WAN/LAN
Recommended Users
24
Max. Users
96
Power Supply
100-240V~50/60Hz 0.5A
Power Consumption
≤15W
Operation Frequency Bands
802.11b/g/n/: 2.400 GHz to 2.483 GHz
802.11a/n/ac: 5.150 GHz to 5.350 GHz
802.11a/n/ac: 5.470 GHz to 5.725 GHz , 5.725 GHz to 5.850 GHz
country-specific restrictions apply
Transmit Power
Regular:
CE EIRP: ≤20dBm (2.4GHz)
≤27dBm (5GHz)
≤20dBm 2400~2483.5MHz(Bluetooth)
Myanmar:
2400~2483.5MHz ≤ 20dBm(EIRP) ,
5150~5350MHz ≤ 23dBm(EIRP) ,
5470~5725MHz ≤ 30dBm(EIRP) ,
5725~5850MHz ≤ 30dBm(EIRP) ,
Operating Temperature
-10 °C to +45 °C (14 °F to 113 °F)
Operating Humidity
5% to 95% Noncondensing
Certifications
CE,RoHS

Wireless

OFDMA
-
MU-MIMO
Yes
BSS Coloring
-
Maximum Number of SSIDs
6
SSID Hiding
Yes
Band Steering
Yes
Guest Wi-Fi
Yes
WPA/WPA2
Yes
WPA3
-
Roaming
Layer 2 Roaming
Blocklist
Yes
Reyee Mesh
Yes
Mesh Pairing by Hardware
Yes
Mesh Pairing by Mesh Button
Yes
Mesh Pairing by Eweb
Yes
Recommended Hop Count
≤2
Wi-Fi Optimization
Yes
QoS (WMM)
Yes
WPS
Yes
Transmission Power Adjustment
Yes

Hardware

CPU
MT7628DAN
Flash
16 MB
RAM/SDRAM
64 MB
Color
White
System LED Indicator
Yes
Reyee Mesh LED Indicator
Yes
Reyee Mesh Button
Yes
Power Button
-
Reset Button
Yes
DC Connector Dimensions
-

WAN

Static IP
Yes
DHCP
Yes
PPPoE
Yes
Learning PPPoE Account & Password
Yes
VLAN Tagging
Yes

LAN

DHCP Server
Yes
Client List
Yes
Static IP Assignment
Yes
Port-Based Flow Control
Yes

Features

IPv6
-
DDNS
-
IPTV
-
Alarm
-
Diagnosis
-
UPnP
-
ARP Binding
-
Port Mapping
-
DMZ Host
-
Rate Limitation of Terminals
-
Hardware Acceleration
-
MAC Address Cloning
Yes
Cloud Management
Yes
Repeater Mode
Yes
WISP Mode
Yes

Security

PPTP VPN Server
-
PPTP VPN Client
-
L2TP VPN Client
-
Parental Control
-
Protect TCP Flood Attacks
Yes
Protect ICMP Attacks
-
Protect UDP Flood Attacks
-

System

Default Access/Password
10.44.77.254
No Password Required by Default
URL Access
-
Local Upgrade
Yes
Online Upgrade
Yes
APP Upgrade
Yes
Syslog
-
Backup
-
Factory Reset
Yes
Language
Chinese
English
Vietnamese
Indonesian
Thai
Arabic
Traditional Chinese
Spanish
Russian
*Specifications are subject to change without prior notice.
